Subcategory
Other Recessed Ltg.
Finish
Combination Finishes
, White
, Red
Option
Energy Star
, LED
, Prop 65
Additional Info
2HR Fire Rated: Tested to comply with UL 263/ASTM E119/CAN-ULC S101-07; White Trim/Red Backplate
Bulb Kelvin
Warm White to Natural Light
Bulb Shape
Integrated LED
Harmonized Codes
9405.11.6010
Warranty
5 Year Limited - Fixtures
CEC
California T24 2016 - 2022 JA8 Listed
CEC Terse
Lawful for sale in California
CEC Web Text
California T24 Listed
Ceiling Aperture
3.875 in. Cutout
Country Of Origin
Cambodia
Dimmable Down To
100 to 10 percent
Dimmable Function
0-10V Dimming
ES Category
Downlight Recessed
ES Unique ID
ESID-2473604
Feature 1
Fire rated up to 2-hours
Feature 2
Red painted backplate for easy identification
Feature 3
5 CCT Selectable
Feature 5
Wet Location Rated
Feature 8
Air Tight Rated
Incandescent Equivalent
60W
Lens Material
Polycarbonate (PC)
Long Description
SATCO|NUVO's Dual Mode 4 inch Flat Lens Fire Rated Downlight is the perfect solution for installations with low ceiling clearance. Designed to provide exceptional illumination, this downlight provides two hours of protection in the event of a fire. Inc
Material
Aluminum / Steel
Max Drywall Thickness
1.181 in.
Mounting Procedure
Ceiling
Operating Frequency
50/60Hz
Operating Temprature
-20C (-4F) to +40C (+104F)
Replaceable Light Source
No
Romance Copy
SATCO|NUVO's Fire Rated Downlights are the perfect solution for installations with low ceiling clearance. Designed to provide exceptional illumination, these downlights provide two hours of protection in the event of a fire. Increase safety and peace o
Safety Listing
cULus - Certified
Short Description
10WLED/4/CFR/CCT/SLF/RD/FL/RND
Sloped Ceiling Compatible
No
Specification Notes
Driver Dimensions: 4.50" x 3.00" x 1.25"
Temperature (CCT)
2700K/3000K/3500K/4000K/5000K
Total Harmonic Distortion
<20%
Manufactured By
Satco Products Inc.
